კატეგორიები: ქსელის მოწყობილობები / დაშვების წერტილი
მოდელი: RG-RAP1200(P)
ბრენდი: Reyee
SKU: 00193
თეგები: reyee, ruijie, wall plate, კედლის, წვდომის წერტილი
| Radio | Dual-stream dual-band |
|---|---|
| Protocol | Concurrent 802.11ac wave2, wave1, 802.11a/b/g/n |
| Operating Bands | 802.11b/g/n ：2.4G ~ 2.4835GHz 802.11a/n/ac ： 5G：5.150～5.350GHz，5.725～5.850GHz |
| Antenna | built-in antenna |
| Spatial Streams | 2.4G 2x2MIMO 5G 2x2MIMO |
| Max Throughput | 2.4G: up to 400Mbps 5G: up to 867Mbps Access rate per AP: 1.267Gbps |
| Modulation | OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM |
| Receive Sensitivity | 11b：-91dBm(1Mbps)，-88dBm(5Mbps)，-85dBm(11Mbps) 11a/g：-89dBm（6Mbps），-80dBm（24Mbps），-76dBm（36Mbps），-71dBm（54Mbps） 11n：-83dBm@MCS0，-65dBm@MCS7，-83dBm@MCS8，-65dBm@MCS15 11ac HT20：-83dBm（MCS0）, -57dBm（MCS9） 11ac HT40：-79dBm（MCS0）, -57dBm（MCS9） 11ac HT80：-76dBm（MCS0）, -51dBm（MCS9） |
| Maximum Transmit Power | 20 dBm(adjustable) |
| Adjustable Power | 1dBm |
| Dimensions | 126mm×86mm×46.3mm(5.0in x 3.4 in x 1.8 in.)(excluding barckets) |
| Weight | ≤0.24kg(excluding barckets) |
| Service Ports | Front： 4 10/100/1000Base-T Ethernet ports LAN1 port supports IEEE.802.3af PoE out Rear： 1 10/100/1000Base-T Ethernet port |
| Management Port | N/A |
| LED Indicator | Single indicator |
| Power Supply | Support PoE (802.3af/at) |
| Power Consumption | ≤8W(max power consumption is 23.4W PoE output included ) |
| Environment | Operating temperature: 0°C～40°C (32℉ to 104℉) Storage temperature: -40°C～70°C (-40℉ to 158℉) Operating humidity: 5％～95％（non-condensing） Storage humidity: 5％～95％（non-condensing） |
| Installation | Wall plate installation |
| Safety Standard | GB4943, IEC 62368-1 |
| EMC Standard | GB9254，EN301 489，EN50155，EN50121，EN55032，EN61000，EN55035 |
| Vibration Standard | IEC61373 |
| Radio Standard | EN300 328, EN301 893 |
| MTBF | >250000H |
| Operating Mode | AP mode and routing mode |
| WLAN | Maximum number of clients: 110 Recommended number of clients: 80 (16 at 2.4GHz, 64 at 5GHz) Up to 8 SSIDs Support SSID hiding Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID SSID-based and radio-based STA limit Support Layer 2 user isolation |
| Roaming | Support Layer 2 and Layer 3 roaming |
| Security | Support PSK authentication Support static blacklist and whitelist Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption |
| Routing | Support static IP address, DHCP, PPPoE Dial Up |
| Management and maintenance | Support unified networking of all network equipment Support local or remote management with Ruijie Cloud app Support local management with web Support remote management with Ruijie Cloud platform |
